Plastic biaxial geogrid



PP Biaxial Geogrid

Biaxial  geogrids have been utilized in pavement construction and soil  stabilization projects throughout the US and worldwide.Biaxial Geogrid  is Strata’s innovative geogrid that is made from extruded polypropylene  which provides superior stiffness, aperture stability and interlock  capabilities for structural reinforcement of paved and unpaved roads.



Biaxial Geogrid  provide structural reinforcement of roads and parking areas through excellent stiffness and interlock capabilities.



Application:

1. Reinforcement and Stabilisation of earth fencing walls, railways, highways and water conservation projects;

2. Reinforcement of road foundations;

3. Retaining walls;

4. Road slope repair and reinforcement;

5. Be used in noise barriers construction.



Technical  data

Index Properties

Test Method

Unit

GG1515

GG2020

GG3030

GG4040

MD  TD

MD  TD

MD    TD

MD  TD

Polymer

--

--

PP

PP

PP

PP

Minimum Carbon Black

ASTM D 4218

%

2

2

2

2

Tensile Strength@ 2% Strain

ASTM D 6637

Kn/m

5      5

7      7

10.5  10.5

14      14

Tensile Strength@ 5% Strain

ASTM D 6637

Kn/m

7      7

14      14

21      21

28      28

Ultimate Tensile Strength

ASTM D 6637

Kn/m

15      15

20      20

30      30

40      40

Strain @ Ultimate Strength

ASTM D 6637

%

13      10

13      10

13      10

13      10

Structural Integrity

Junction Efficiency

GRI GG2

%

93

93

93

93

Flexural Rigidity

ASTM D 1388

Mg-cm

700000

1000000

3500000

10000000

Aperture Stability

COE Method

mm-N/deg

646

707

1432

2104

Dimensions

Roll Width

--

M

3.95

3.95

3.95

3.95

Roll Length

--

M

50

50

50

50

Roll Weight

--

Kg

39

50

72

105

MD denotes Machine direction. TD denotes transverse direction.

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q:Is the quality of your products stable?

A:The company has a complete QC system, and each batch of products will be sampled and the samples will be kept for 5 years.

Q:Can you do OEM?

A:Yes, of course. We can produce the products as per your request.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 10-15 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?

A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance,balance before shipment. If you have another question, please feel free to contact us at any time.
