Uniaxial Plastics Geogrid is mainly used in highway and railroad to
reduce the subsiding difference ofthe roadbed and bridgehead, lower the
vibration of the vehicles and the roadbed, slower the roadbed structure
distortion to guarantee the security and comfort.
To lay the geogrid in the backfill soil can increase the shearing
strength and the whole character in middle terms, reduce the mid-term
filling quantity, make the soft base more convenient, lower the
construction cost.When used in the dam design, it can be as the muscle
structure to improve the bearing distortion performance of the dam to
avoid breaking.
Uniaxial Plastics Geogrid is widely used in dyke, tunnel, wharf, highway, railway, construction and other fields
Product Feature:
Materials:polypropylene (PP) or HDPE
Tensile strength:25 ~ 300kn/m
WIdth:1m ~3m
PP uniaxial geogrid technical datas:
| Specs | Tensile strength /(kN/m) | Tensile strength at 2% strain (kN/m) | Tensile strength at 5% Strain (kN/m) | Elongation (%) |
| TGDG35 | ≥35.0 | ≥10.0 | ≥22.0 | ≤10.0 |
| TGDG50 | ≥50.0 | ≥12.0 | ≥28.0 | |
| TGDG80 | ≥80.0 | ≥26.0 | ≥48.0 | |
| TGDG120 | ≥120.0 | ≥36.0 | ≥72.0 | |
| TGDG160 | ≥160.0 | ≥45.0 | ≥90.0 | |
| TGDG200 | ≥200.0 | ≥56.0 | ≥112.0 |
PE uniaxial geogrid technical datas:
| Specs | Tensile strength /(kN/m) | Tensile strength at 2% strain (kN/m) | Tensile strength at 5% Strain (kN/m) | Elongation (%) |
| TGDG35 | ≥35.0 | ≥7.5 | ≥21.5 | ≤15.0 |
| TGDG50 | ≥50.0 | ≥12.0 | ≥23.0 | |
| TGDG80 | ≥80.0 | ≥21.0 | ≥40.0 | |
| TGDG120 | ≥120.0 | ≥33.0 | ≥65.0 | |
| TGDG160 | ≥160.0 | ≥47.0 | ≥93.0 |
